  • CCW Horizontal MiraPLY 4' x 50' Roll

Mfr:Carlisle Coatings & Waterproofing

CCW Horizontal MiraPLY 4' x 50' Roll

(0)(0)
Item #: CCWMIRAPLY-H.RL*NA

Mfr. Part #: 317109

Q&A(0)

MiraPLY-H with SeamLOCK Technology is a nominal, 70-mil horizontal grade, self-adhering, blindside waterproofing membrane. The dual laminate membrane fuses a 45-mil thick, reinforced TPO sheet to a 25-mil butyl adhesive coating, combining two of the most time-tested waterpro...

View More Details

In Stock

Available: 20

Case Quantity: 1

Location

Available

Anaheim, CA

17

Burbank, CA

3

Denver, CO

0

Ontario, CA

0

Salt Lake City, UT

0

San Diego, CA

0

San Marcos, CA

0

(*) Minimum Quantity: 1

Better Together

Buy all 2

Subtotal $1,899.93

About This Product

Details

MiraPLY-H with SeamLOCK Technology is a nominal, 70-mil horizontal grade, self-adhering, blindside waterproofing membrane. The dual laminate membrane fuses a 45-mil thick, reinforced TPO sheet to a 25-mil butyl adhesive coating, combining two of the most time-tested waterproofing technologies used worldwide. With the addition of new SeamLOCK pre-primed strips, MiraPLY-H is not only tough, durable and flexible, it is easy to install.

  • Durable - Pliable TPO layer has superior puncture resistance compared to HDPE, making MiraPLY the best system to meet the active demands of heavily trafficked construction sites and uneven rocky substrates.
  • Tenacious Bond - Butyl Alloy adhesive creates a permanent, chemical bond with placed concrete to eliminate water migration between membrane and concrete, while ensuring protection against ground settlement beneath slabs.
  • Efficient Application- Light-weight, kick-out roll for fast installation less labor- Factory installed SeamLOCK pre-primed, peel-and go-strips eliminates primer for enhanced adhesion and easier side lap construction. Retains strong bond in both wet and dry, dusty site conditions.- Elastic properties make cutting membrane easy with fewer hand injuries
  • Fully bonds to concrete
  • Excellent resistance to most chemicals (i.e., acids and bases)
  • Effective Radon barrier
  • Bridges cracks in concrete

Applications

  • Below elevator pits
  • Under slabs and footings
  • Below-grade structural slabs

Packaging

  • 4' x 50' (1.22 m x 15.24 m) rolls. Weight: 80 lbs (36 kg)

Documents

CCW Miraply-H Documents

Specifications

CCW Miraply-H Specifications
